The electrical connector is installed on the tow
hook, and it will be extended along with the
hook after turning on the trailer hook on the CID.
The connector can be used after the protective
cover is opened.
FDXWLRQ
Do not use high-pressure water guns to
clean the electrical connector when it is not
connected to the trailer interface to prevent
water damage.
The vehicle is equipped with a 13-pin electrical
connector coil, following the ISO 11446:2004
standard for the power supply socket. Each pin
has specific functions as following:
Pin
Number
Color Function
1 Yellow Left turning lamp
