XPENG G9 - Four-Wheel Alignment Parameters

)RXU:KHHO$OLJQPHQW3DUDPHWHUV
Project Name Type I Type II Type III Type IV
Single-Sided
Front Wheel Toe-
In
3′±6′ 0′±6′
Single-Sided
Front Wheel
Camber Angle
-0.45°±0.5° -0.6°±0.5°
Single-Sided
Kingpin Caster
5.6°±1.4° 5.9°±1.4°
Single-Sided
Kingpin Inclination
7.9°±1° 8.1°±1°
Single-Sided Rear
Wheel Toe-In
5′±6′ 8′±6′
Rear Wheel
Camber Angle
-1.0°±0.5° -1.4°±0.5°
