XPENG G9 User Manual

2Blue
Rear fog lamp or reverse
lamp
3 White
1-8 pin common ground
wire
4 Green Right turning lamp
5 Brown Right turn signal
6 Red Brake light
7Black
Left turn signal
(Mergeable with 5)
8 Pink Reverse lamp
9 Orange Jump-start the battery
10 Gray Battery or refrigerator
11
Black
and
white
10-pin ground wire
12
Blue and
white
Spare wire
13
Red and
white
9-pin ground wire
5HDUYLHZPLUURUDQGEUDFNHW
The exterior rearview mirrors of the towing
vehicle must comply with the regulatory
requirements. If not, please install appropriate
trailer rearview mirrors.
&RPIRUW(TXLSPHQWV
138
6
