• Do not wait for warning messages from
the parking radar, but brake as required to
ensure vehicle safety.
• The parking radar only emits warning
messages when obstacles are detected,
so it may not issue warnings, may delay
the issuing, or may produce unnecessary
warnings. Relying entirely on the parking
radar for potential crash warnings may result
in severe personal injury or death.
)XQFWLRQ$FWLYDWLRQ
When shifted to D gear, the front bumper's
ultrasonic radar starts working. When shifted to
R gear, all ultrasonic radars are activated.
:DUQLQJLQWHUIDFH
When the parking radar system is activated,
ICM will simulate the approximate direction and
distance of obstacles relative to the vehicle.
Green indicates a greater distance, while red
indicates a very close one. The distance between
the vehicle and the nearest obstacle is also
displayed numerically below.
3DUNLQJ$VVLVWDQFH
90
5
