Yamaha FZ09E - Page 103

1. Rear frame
2. Clamp
3. Re ar brake caliper
4. Rear brake hose
5. Swingarm assembly
A. Install th e clamp faci ng th e direclion in the illuslra-
tion.
B. Make sure to i
ns tall the clamp all t he way in t he
rear frame.
C. Fasten
th e protector of the br ake hose wit h the
clamp. Install the mating section on the top of t
he
vehicle.
D. Make su
re to install the clamp all t he way in t he
sw i ng arm assembl y.
E. Install the brake pipe so th at it aligned wit h the cut-
out in the caliper.
CABLE ROUTING
2-68
