• Coolant reservoir
• Coolant reservoir cover
• Coolant reservoir bolts
9. Fill:
Coolant reservoir
bolt
(MS)
0.5 Nm (0.05 m·kgf, 0.37
ft
·lbf)
Coolant reservoir
bolt
(M6)
9 Nm (0.9 m·kgf, 6.5 ft·lbf)
• Cooling system
(with the speci
fied
amount of the recom-
mended coolant)
Recommended antifreeze
High-quality ethylene
glycol
anti-
freeze containing corrosion
inhibitors
for
aluminum engines
Mixing ratio
1
:1
(ant
ifre
eze: water)
Radiator capacity (including all
routes)
1.93 L (2.04 US
qt,
1. 70 Imp.qt)
Coolant reservoir capacity (up
to
the maximum level mark)
0.25 L (0.26 US
qt,
0.22 Imp.qt)
Handling notes for coolant
Coolant is potentially harmful and should be
handled with special care.
EWA
1
3CMO
A WARNING
•
If
coolant splashes
in
your
eyes, thorough-
ly
wash
them
with water and
consult
a doc-
tor.
•
If
coolant
splashes
on
your
clothes,
quickly
wash
it
away
with
water and then
with
soap
and water.
•
If
coolant
Is
swallowed, Induce vomiting
and get Immediate medical attention.
NOTICE
~~~~~~~~~~~~~
• Adding water instead
of
coolant lowers the
antifreeze concentration
of
the coolant. If
water
is
used instead
of
coolant check, and
if
necessary, correct
th
e antifreeze concen-
tration
of
the coolant.
• Use
only
distilled water. However,
if
dis-
tilled water
is
not
available,
soft
water
may
be
used.
•
If
coolant comes
in
to
contact with painted
surfaces, immediately wash
them
with
wa-
ter.
• Do not
mix
different types
of
antifreeze.
PERIODIC MAINTENANCE
1 O.lnstall:
•
Rad
iat
or
cap stopper
•
Rad
iat
or
cap
•
Rad
iat
or
cap bolt
Radiator
cap
bolt
5 Nm (0.5 m·kgf, 3.6 ft·lbf)
11.Fill:
• Coolant reservoir
(wi
th th
e recommended coolant
to
the max
i-
mum level mark "
a")
12.lnsta
ll
:
• Coolant
reservoir cap
13.Start the engine, warm it up for several min-
utes, and th
en
tum it off.
14.Check:
• Coolant level
Re
fer
to
"CHECKING THE COOLANT LEV-
EL"
on page 3-25.
TIP
~~~~~~~~~~~~~~
Before checking the coolant level, wait a few
minutes until the coolant has settled.
EA.SIRC13l3
CHECKING THE FRONT BRAKE LIGHT
SWITCH
Refer
to
"ELECTRICAL COMPONENTS" on
page 8-85.
"""""
ADJUSTING THE REAR BRAKE LIGHT
SWITCH
TIP
~~~~~~~~~~~~~~
The rear brake light switch is operated by move-
ment of
th
e brake pedal. The rear brake light
swi
tc
h is properly adjusted wh
en
the brake light
comes
on
just before the braki
ng
effect starts.
1. Check:
•
Rea
r brake light operation
tim
ing
Incorrect~
Adjust.
2. Adjust:
• Rear brake light operation
tim
ing
3-27
