a. WHEN THE TRANSMISSION IS IN NEU-
TRAL
b. WHEN THE SIDESTAND IS UP AND THE
CLUTCH LEVER IS PULLED TO THE HAN-
DLEBAR
1. Ba
tt ery
2. Main fuse
3. Main sw i tc h
4. I gn ition fuse
5.
Start/engine stop switch
6.
Start in g circuit cut-off relay
7. Diode
8.
Clutch switch
9.
Sidestand switch
10.Gear position sensor (neutral c
ir cuit)
11.Dio
de
12.Starter relay
13.Start
er motor
ELECTRIC STARTING SYSTEM
8-10
