1. Front brake master cy linder
2. Throttle cable
3. Rubber cover
4. Handlebar
5. Front b
ra ke hose
A. When installi ng th e rubber cover. silicone water or
soapy water may
be appli ed to the inside of the
rubb er cover .
B. Detailed drawi ng of ar ou nd t he fr ont brake master
cy linder
C. Straight line para
ll el to the fr on t brake master cy l-
inde r r ese rvo ir cap
D. 3- 13'
E. Ce nter of the metal fitting tor t he fr ont brake ho se
CABLE ROUTING
2-42
