1. Fr ame
2. F ue l ta nk
3. F ue l pu mp
4. Fuel tank drain hose
5. Fuel
ta nk breather hose
6. Clip
7. Fuel hose assembly
A. In se rt t he fuel tank drain hose up to the section
where the fuel
ta nk pi pe increases in diameter.
In stall it so t hat the white paint mark faces th e
rearward.
B.
In stall the clip so that the end is on the paint ma rk.
Do not put it on t he clip spool (guard). Point the
end to t
he rear, and store it inside to the fuel hose.
C. Align t
he fu el pu mp posit io ning to the inner pa nel
marki
ng (visual guide d ur i ng install at ion).
D. In se rt the fuel tank breather h ose up to the section
where the fuel
ta nk pi pe increases in diameter.
In stall it so t hat the yell ow paint mark faces th e
rearward.
CABLE ROUTING
2-48
