9-153
P0335
4. Installed condition of crankshaft position sensor.
• Check for looseness or pinching.
• Check the gap (0.85 mm (0.03 in)) between the crankshaft position sensor and the generator rotor.
Gy B
Gy B
Gy
LLVP
P/WY/LL/B
B/LB/LBr/WGy/GB/YL/W
W/YW/GG/WG/WL/WL/Y
Gy
LLVP
P/WLg/LO/WY/LL/B
B/LB/LBr/WGy/GG/LBr/LB/YL/W
W/YW/GG/WG/WLg/BL/WL/Y
L/W
WW
L/W
BB
L/B L/B Y/B Y/B
L/R L/R L/RL/RB/L
B
B/L
BBBBB
A
B
1
1
3
*
3
**
2
*. MTN890
**. MTN890D
Is resistance ∞ Ω?
YES
→ Go to step 4.
NO
a. Replace the wire harness.
b. Crank the engine, and then check the condition of the DTC using the malfunction mode of the
YDT.
Is it in the “Recovered” condition?
YES
→ Go to step 7, and complete the service.
NO
→ Go to step 4.
Is check result OK?
YES
→ Go to step 5.
NO
a. Reinstall or replace the sensor.
b. Crank the engine, and then check the condition of the DTC using the malfunction mode of the
YDT.
Is it in the “Recovered” condition?
YES
→ Go to step 7, and complete the service.
NO
→ Go to step 5.
To Next Page
