4.6 Data Transfer without Using the MPE720
4.6.2 Using the MPLoader Ver.4
4-75
MPL700 Features
The MPL700 provides an easy way to load updated applications to the end-user systems with-
out using the MPE720. Therefore, unlike the MPE720, it does not have functions for system
configuration definitions, programming, monitoring, and other operations.
The application provider sends the compressed application file to the user. The end user can
specify the received compressed file in the MPL700 to load the application into the Machine
Controller.
Overall Workflow
The following figure shows the dataflow until the updated application is loaded into the end-
user system (CPU Module) using the MPL700 Client.
: Create the compressed file for sending with the compressed sending function of the
MPE720 (version 5.10 or higher).
This is the same function as the one supported by the MPL700 Server.
: Load the compressed file that was provided into the MP3000-series Machine Controller
with the MPL700 Client.
indicates transfer via a network, removable disk, or other methods that are not automatically
supported by this software.
Refer to the following manual for details on the features and operation of the MPLoader.
MP2000/MP2000-series MPLoader Ver.4 User’s Manual (Manual No.: SIEP C880761 01)
MPL700
Client
Application Provider End User
Controller
MPE720
(version 5.10 or
higher)
Create compressed le to send.
Send it as an email attachment.
Extract the application environment.
Load into the Controller.
To Next Page
