YASKAWA MP3000 Series - Combinations of MP2000 MP3000-Series Products; Combinations of MP3000-Series Products

1.1 Combinations of MP2000/MP3000-series Products
1.1.1 Combinations of MP3000-series Products
1-2
1.1 Combinations of MP2000/MP3000-series Products
The following figure shows the combinations of Units and Modules in MP3000-series Machine
Controllers.
The MP2000 Extension Rack Unit allows you to use MP2000-series Motion Control Modules,
Communications Modules, and I/O Modules in a Machine Controller.
Refer to the following section for details on product combinations.
1.1.2 Combinations of MP2000-series Products
1.1.1 Combinations of MP3000-series Products
MP3200
MP3300
Product Name Abbreviation Description
MP3200
(CPU-201,
CPU-202)
CPU Unit
CPU-201
CPU + Ethernet +
SVC

CPU-202
CPU + Ethernet +
SVC

Base Units
MBU-B03 3 slots for MP2000 Optional Modules 
MBU-B05 5 slots for MP2000 Optional Modules 
MBU-B08 8 slots for MP2000 Optional Modules 
Power Supply Units
PSA-12 AC Power Supply Unit, 12 A 
PSD-12 DC Power Supply Unit, 12 A 
Rack Expansion Inter-
face Units
EXU-001 For the Main Rack

Ver. 1.06 or
higher
EXU-002 For Expansion Racks

Ver. 1.06 or
higher
Product Name Abbreviation Description
MP3300
(CPU-301,
CPU-302)
CPU Module
CPU-301
(16 axes)
Standard CPU Module, Built-in M-III (16 axes), User memory:
15 MB

CPU-301
(32 axes)
Standard CPU Module, Built-in M-III (32 axes), User memory:
31 MB

CPU-302
(16 axes)
High-speed CPU Module, Built-in M-III (16 axes), User mem-
ory: 15 MB

CPU-302
(32 axes)
High-speed CPU Module, Built-in M-III (32 axes), User mem-
ory: 31 MB

Base Units
MBU-303 24-VDC power input, 3 slots for MP2000 Optional Modules

MBU-304 24-VDC power input, 1 slot for MP2000 Optional Modules

