2.2 MP3300 Installation

2.2.2 DIN Rail Mounting

2-28

2.2.2

DIN Rail Mounting

Carefully line up the DIN rail locks with the locking positions.

Refer to the following section for details on installation.

2.1.2 DIN Rail Mounting on page 2-7

Using the MBU-303

Locking position

Lock release position
