2.2 MP3300 Installation
2.2.1 Mounting with Screws
2-26
2.2
MP3300 Installation
You can use either of the following methods to install an MP3300 Controller.
• Screw mounting
• DIN rail mounting
Refer to the following appendix for more information on the installation and application require-
ments.
A.2 MP3300 Installation and Usage Conditions on page A-5
2.2.1
Mounting with Screws
Secure the Base Unit with screws at four places.
Using the MBU-303
Use screws to secure the 4 places shown in the following figure.
