3.3 Creating a Project File
3.3.2 Creating a Project File
3-8
3.3.2 Creating a Project File
Use the following procedure to create a project file.
1. Start creating a project file with either of the following two methods.
• Select New from the Project Menu in the Start Tab Page.
• Select File − Create New Project from the menu bar.
2. Open the target folder, enter the file name, select the file type, and specify the Machine
Controller to use.
If a project file was being edited, a dialog box will be displayed asking whether to compile
and save the project file. The buttons perform the following actions:
Yes Button: The current project will be compiled and saved by overwriting the previ-
ously version, and editing will be ended.
No Button: Editing will be ended without compilation and saving any changes.
Cancel Button: Creating a project will be canceled and you can continue to edit the
current project.
 File name
Enter the name of the project file to create.
Note: The file name cannot contain any of the following characters: / \ :* " < > |
 Save as type
Select the file extension for the project file from the list of possible extensions.
MP3000 Series: .YMW7
 Series
Select the series of the Machine Controller to use.
 Controller
Select the model of the CPU Unit/CPU Module.
