5.3 Monitoring Machine Operation
5.3.3 Realtime Tracing
5-44
The Trace Type Dialog Box contains the following items:
No. Item Description
Real-Time Trace This button displays up to 64 points of trace data in realtime.
Trace Manager This button displays up to 64 points of trace data in a graph.
XY Trace
This button displays the position data of two orthogonal axes in a 2-
dimensional graph.
Open This button starts the selected type of trace.
Cancel
This button returns you to the main window without starting the selected
type of trace.
