A.2 MP3300 Installation and Usage Conditions
A.2.1 Environmental Conditions
A-5
AppA
Controller Specifications
A.2
MP3300 Installation and Usage Conditions
Install the MP3300 Controller in an environment with the following conditions.
A.2.1
Environmental Conditions
Control Panel Cooling Method
The components that are used in the MP3300 require the ambient operating temperature to be
between 0 and 60°C. Use one of the methods described below to ensure adequate cooling in
the control panel.
Control Panels with Natural Cooling
• Do not mount the MP3300 at the top of the control panel, where the hot air that is generated
inside the panel collects.
• Leave sufficient space above and below the MP3300, and maintain adequate distances from
other devices, cable ducts, and other objects to ensure suitable air circulation.
• Do not mount the Machine Controller in any direction other than the specified direction.
• Do not mount the Machine Controller on top of any device that generates a significant
amount of heat.
• Do not subject the Machine Controller to direct sunlight.
Item Specification
Ambient Operating Temperature 0 to 60°C (Forced cooling is required if 55°C is exceeded.)
Ambient Storage Temperature −25 to 85°C
Ambient Operating Humidity 10% to 95% RH (with no condensation)
Ambient Storage Humidity 10% to 95% RH (with no condensation)
Pollution Degree Conforms to JIS B 3502 Pollution Degree 2.
Corrosive Gas There must be no combustible or corrosive gases.
Operating Altitude 2,000 m max.
If the ambient temperature exceeds 55°C, use forced-air cooling.
To Next Page
