5.1 Debugging Ladder Programs
5.1.4 Searching and Replacing in Programs
5-9
5
Debugging Programs
5.1.4 Searching and Replacing in Programs
You can search for variables, instructions, and comments in a specified program. You can also
search for and replace registers and register comments.
The following section describes how to search for and replace text in programs.
Searching in Programs
1. Bring the program to search to the front in the Ladder Editor, and then select Edit − Find
from the menu bar.
The Search Dialog Box will be displayed.
2. Click the Variable, Instruction or Comment Tab to set the search criteria.
Variable Tab Page:Allows you to search for variables and registers. You can also enter the variable by
copying it from the Variables Pane.
Instruction Tab Page:Enter the name of the instruction or the assigned instruction key in the Instruc-
tion Box.
The Variable Box is displayed when an instruction is entered in the Instruction
Box. If the SEE instruction is entered in the Instruction Box, Variable changes
to Program Name. You can also enter the variable by copying it from the Vari-
ables Pane.
