5.2 Debugging a Motion or a Sequence Program
5.2.9 Alarm Monitor
5-28
5.2.9
Alarm Monitor
Use this dialog box to check any alarms that occur during motion program execution.
No. Name Description
Task Displays the task numbers.
Program name Displays the program numbers.
Block number Displays the block numbers where the alarms occurred.
Axis number Displays the axis numbers where the alarms occurred.
Status (alarm name) Displays the names of the alarms.
Alarm Contents This box displays a description of the alarm.
Corrective Action
This box displays information on correcting the condition that
caused the alarm.
OK
The OK Button closes the Motion Alarm Dialog Box and returns to
the Motion Editor Tab Page.
