4.2 Creating Ladder Programs
4-53
4
Creating User Programs
4.2 Creating Ladder Programs
Use the following procedure to create a ladder program.
1. Select Programming - Ladder program in the Launcher.
The Ladder Pane will be displayed.
2. Right-click High-speed under Ladder program, and select New.
The Create New Program Dialog Box will be displayed.
3. Click the OK Button.
The Ladder Editor will start.
The following example shows how to create a high-speed program, but low-speed and startup
programs can be created in essentially the same way.
Note
Right-click.
