2.1 MP3200 Installation
2.1.6 Battery Installation and Replacement
2-15
2
Installation and Connections
When Using the CPU-201
1.
Confirm that the power supply to the MP3200 is turned OFF.
2.
Open the battery holder on the bottom of the CPU Unit.
3.
Securely connect the lead connector of the Battery to the connector in the CPU Unit.
4.
Press the connector back into the CPU Unit.
To Next Page
