2.1 MP3200 Installation

2.1.1 Screw Mounting

2-3

Installation and Connections

The installation procedure is as follows:

Attach the Screw Mounting Attachment to the right end of the Controller.

In the same way as when mounting to DIN rail, use the rail locks to secure the Rack

Support Bracket.

Screw Mounting Attachment

Locking

position

Lock release position
