2.1 MP3200 Installation

2.1.1 Screw Mounting

2-6

Use screws to secure the 4 places shown in the following figure.

Note: 1. Recommended screws: M4 × 14 mm min.

2. Use a screwdriver with a shaft that is at least 13 cm long.
