MPE720 Engineering Tool Version Number
In this manual, the operation of MPE720 is described using screen captures of MPE720 version 7.
For this reason, the screen captures and some descriptions may differ for MPE720 version 6.
Indication of Reverse Signals
In this manual, the names of reverse signals (ones that are valid when low) are written with a for-
ward slash (/) before the signal name, as shown in the following example:
Notation Examples
• S-ON
= /S-ON
• P-CON
= /P-CON
Terms Used to Describe “Torque”
Although the term “torque” is commonly used when describing rotary Servomotors and “force” is
used when describing linear Servomotors, this manual uses “torque” when describing either one
(excluding parameter names).
Copyrights
• MECHATROLINK is a trademark of the MECHATROLINK Members Association.
• DeviceNet is a registered trademark of the ODVA (Open DeviceNet Venders Association).
• PROFIBUS is a trademark of the PROFIBUS User Organization.
• Ethernet is a registered trademark of the Xerox Corporation.
• Other product names and company names are the trademarks or registered trademarks of the
respective company. “TM” and the
® mark do not appear with product or company names in this
manual.
Visual Aids
The following aids are used to indicate certain types of information for easier reference.
Indicates precautions or restrictions that must be observed.
Indicates alarm displays and other precautions that will not result in machine dam-
age.
Indicates items for which caution is required or precautions to prevent operating mis-
takes.
Indicates operating or setting examples.
Indicates supplemental information to deepen understanding or useful information.
Indicates definitions of difficult terms or terms that have not been previously
explained in this manual.
