Yealink SIP-T48G Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series/CP860 IP Phones
516
Example of a SIP INFO message:
Via: SIP/2.0/UDP 10.3.20.14:5060;branch=z9hG4bK175716007
From: "1009" <sip:1009@10.2.1.48:5060>;tag=1385842459
To: <sip:1006@10.2.1.48:5060>;tag=2383911905
Call-ID: 0_1289812066@10.3.20.14
CSeq: 3 INFO
Contact: <sip:1009@10.3.20.14:5060>
Max-Forwards: 70
User-Agent: Yealink SIP-T23G 44.80.0.60
Record: off
Content-Length: 0
URL Record
When a user presses a URL record key for the first time during a call, the IP phone sends
an HTTP GET message to the server.
Example of an HTTP GET message:
GET /URLRecord/record.xml HTTP/1.1\r\n
Request Method: GET
Request URI: /URLRecord/record.xml
Request version: HTTP/1.1
Host: 10.3.5.97:8080\r\n
User-agent: Yealink SIP-T23G 44.80.0.60 00:15:65:74:B1:50\r\n
If the recording is successfully started, the server will respond with a 200 OK message.
Example of a 200 OK message:
<YealinkIPPhoneText>
<Title>
</Title>
<Text>
The recording session is successfully started.
</Text>
<YealinkIPPhoneText>
If the recording fails for some reasons, for example, the recording box is full, the server
will respond with a 200 OK message.
Example of a 200 OK message:
<YealinkIPPhoneText>
<Title>
</Title>
<Text>
Probably the recording box is full.

Yealink SIP-T48G Specifications

General

Expansion module support	Yes
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Volume control	-
Display diagonal	7 \
Display resolution	800 x 480 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
AC adapter input voltage	100 - 240 V
Number of handles included	1 pc(s)

Weight and Dimensions

Width	266 mm
Height	185 mm
