YOKOGAWA ADMAG AXR User Manual

<8. OPERATION VIA HART CONFIGURATION TOOL (HART 5)>
8-3
IM 01E30D01-01EN
8.4 Basic Setup
 ConrmationandChangeofTagand
Device Information
The tag number and device information can be
checked as follows:
• Thelocationforthetagnumberanddevice
information
(DD)
Tag DeviceSetup→DetailedSetup
→Basicsetup→Tag
Descriptor DeviceSetup→DetailedSetup
→Deviceinformation→Fielddevice
information→Descriptor
Message DeviceSetup→DetailedSetup
→Deviceinformation→Fielddevice
information→Message
Date DeviceSetup→DetailedSetup
→Deviceinformation→Fielddevice
information→Date
(DTM)
Tag EasySetup→Tag
orConguration→HART→Tag
Descriptor Conguration→Deviceinfomation1
→Descriptor
Message Conguration→Deviceinfomation1
→Message
Date Conguration→Deviceinfomation1
→Date
When changing the tag number or device
information, enter the information directly within the
following limitations.
Item Number and characters
Tag 8
Descriptor 16
Message 32
Date 2/2/2 (mm/dd/yy)
• mm:month
• dd:day
• yy:year
8.5 ParametersConguration
TheparameterstructureoftheHARTconguration
tool is hierarchical.
Read Section 8.9 or Section 8.10, Menu Tree
Example for the corresponding parameters.
The menu tree shows a cross-reference of the
parameters for HART and BRAIN.
Read Chapter 6 for the functions of parameters.
NotethatsomedisplayparametersofAXRare
differentfromthoseofHARTcongurationtools.
8.6 Data Renewing
TherearetwomethodstoloadtheAXRdata
from/toHARTCongurationTool---periodicdata
renewing and discretionary data renewing. Read
Section 8.9 or Section 8.10 menu tree for each
corresponding parameter.
(1) Periodic Data Renewing
The data is updated 0.5 to 2 second cycles. The
parameter of this type is marked as “D” in “Data
Renewing” of Section 8.9 or Section 8.10 menu
tree.
(2) Discretionary Data Renewing
 Thedatacanbeloadedfrom/totheAXRwhen
thedatasaveisnishedtotheConguration
Tool. The parameter of this type is marked
as “S” in “Data Renewing” of Section 8.9 or
Section 8.10 menu tree.
NOTE
TheAXRisnotabletosetparametersviaits
display unit during a communication of the HART
CongurationTool.
