<5. BASIC OPERATING PROCEDURES (USING THE DISPLAY UNIT)>
5-1
IM 01E30D01-01EN
5. BASIC OPERATING PROCEDURES (USING THE DISPLAY UNIT)
Both of four push button and magnet switches can
be used for setting. The magnet switches can be
used to set parameters without opening the case
cover.
The magnet switches need operational magnets
(optional code BM). These are also available as
part number F9840PA.
Users can choose a language on indicator from
English, Japanese, German, French, Italian, and
Spanish.
This chapter will provide a description of basic
datacongurationandthemethodstobeused
withthefoursettingswitches.TheAXRcanalso
beoperatedusingacongurationtool(Such
as handheld Brain Terminal (BT200), a HART
CongurationToolorFieldMate,etc.).(Read
Chapter 7 to Chapter 9.)
WARNING
Be sure to set parameters as “Protect” on the
writeprotectfunctionafternishofparameter
setting work.
Read Chapter 6 Menu P and Subsection 11.3.2,
how to use the write protect function in detail.
CAUTION
When using this instrument for a long time in
conditions of high temperature and humidity, the
visibility of the display unit may deteriorate. In
this case, it is necessary to replace the display
unit.
CAUTION
Precautions for Push Button Switches
• Openthecoverwhenoperatingpushbutton
switches. Read Section 11.2 for details on
opening the cover.
• Do not open the cover in wet weather or high
humidity in order to prevent condensation.
The push button switches cannot be used
in these conditions as the cover would need
to be opened. In this case, use magnet
switches to set parameters.
• Do not touch the push button switches with
wet or dirty hands.
NOTE
Precaution for Magnet Switches and
Operational Bar-Magnet
(1) A bar-magnet with its case is attached
withanAXRwhentheoptionalcodeBMis
chosen at the same time. This bar-magnet
with its case is also available as part number
F9840PA.
(2) The bar-magnet should be used for the
parametersettingofAXRfromitsoutside
glass window only.
(3) The switch operation should be done under
the condition of closing the cover case
outside its glass window.
(4) Do not hit the bar-magnet to the glass of the
cover so strongly.
(5) If dirt, dust or other substances surfaces on
the display panel glass, wipe them clean with
a soft dry cloth.
(6) Do not make a condition of closing the
bar-magnettotheowtubeofAXRinorder
topreventgivinganinuenceofmagnetic
distributioninsidetheowtubeandofthe
accuracyofAXR.
(7) Do not bring the bar-magnet near equipment
susceptibletomagneticeldsuchas
magnetic cards, medical equipment, etc.
(8) Keep the bar-magnet in the case because of
the powerful magnetic force.
