1. INTRODUCTION
This instrument has been adjusted at the factory
before shipment.
To ensure correct use of the instrument, please
read this manual thoroughly and fully understand
how to operate the instrument before operating it.
NOTE
This manual describes the hardware and
softwarecongurationofAXRintegralowmeter.
NOTE
When describing the model name like
AXRC in this manual, “” means any
of the following.
025, 040, 050, 065, 080, 100, 150, 200
WARNING
WhenusingtheAXRinaSafetyInstrumented
Systems (SIS) application, read Appendix 1 in
this manual. The instructions and procedures in
the appendix must be strictly followed in order
to maintain the designed safety integrity of the
owmeter.
The manuals can be downloaded from the website
of Yokogawa or purchased from the Yokogawa
representatives.
Websiteaddress:http://www.yokogawa.com/d/
Model Style Code
AXRG
S2
AXRC
 Regarding This User’s Manual
• Thismanualshouldbeprovidedtotheend
user.
• Beforeuse,readthismanualthoroughlyto
comprehend its contents.
• Thecontentsofthismanualmaybechanged
without prior notice.
• Allrightsarereserved.Nopartofthismanual
may be reproduced in any form without
Yokogawa's written permission.
• Yokogawamakesnowarrantyofanykindwith
regard to this material, including, but not limited
to, implied warranties of merchantability and
suitability for a particular purpose.
• Allreasonableefforthasbeenmadetoensure
the accuracy of the contents of this manual.
However, if any errors or omissions are found,
please inform Yokogawa.
• Yokogawaassumesnoresponsibilitiesforthis
product except as stated in the warranty.
• Pleasenotethatthisuser'smanualmaynot
berevisedforanyspecicationchanges,
construction changes or operating part changes
that are not considered to affect function or
performance.
• Thereisnodescriptiononthismanualwhichis
forspecialspecications.
• Ifthecustomeroranythirdpartyisharmedby
the use of this product, Yokogawa assumes
no responsibility for any such harm owing to
any defects in the product which were not
predictable, or for any indirect damages.
 SafetyandModicationPrecautions
• Thefollowinggeneralsafetyprecautionsmust
be observed during all phases of operation,
service, and repair of this instrument. Failure
to comply with these precautions or with
specicWARNINGSgivenelsewherein
this manual violates safety standards of
design, manufacture, and intended use of the
instrument. Yokogawa assumes no liability
for the customer's failure to comply with these
requirements. If this instrument is used in
amannernotspeciedinthismanual,the
protection provided by this instrument may be
impaired.
• Yokogawawillnotbeliableformalfunctionsor
damageresultingfromanymodicationmade
to this instrument by the customer.
• Thefollowingsafetysymbolmarksareusedin
this user's manual and instrument.
WARNING
A WARNING sign denotes a hazard. It calls
attention to procedure, practice, condition or the
like, which, if not correctly performed or adhered
to, could result in injury or death of personnel.
