<9. OPERATION VIA HART CONFIGURATION TOOL (HART 7)>
9-2
IM 01E30D01-01EN
CongurationTool,downloadthemfromtheHART
ofcialsite,otherwise,contacttherespective
vendorsoftheCongurationToolforitsupgrade
information.
1. ConrmationofthedevicerevisionforAXR
 ConnecttheCongurationTooltotheAXR.
The device revision can be checked as follows.
[Root Menu]→Review→Review4→Flddevrev
2. Conrmationofthedevicerevisionforthe
HARTCongurationTool
(1) TurnonthepoweroftheCongurationTool
under the standalone condition.
(2) ConrmtheinstalledDDrevisionin
accordance with the procedure of the
CongurationTool.Readitsmanualhowto
conrmitindetail.
9.3 InterconnectionbetweenAXRandHARTCongurationTool
TheHARTCongurationToolcaninterfacewiththeAXRfromthecontrolroom,theAXRsite,oranyother
wiringterminationpointintheloop,providedthereisaminimumloadresistanceof250Ωbetweenthe
connectionandthereceivinginstrument.Tocommunicate,itmustbeconnectedinparallelwiththeAXR,and
the connections must be non-polarized. Figure 9.3 illustrates the wiring connections for a direct interface at the
AXRsite.TheHARTCongurationToolcanbeusedforremoteaccessfromanyterminalstripaswell.
AXR
F0903.ai
USB
FieldMate
modem
Control room
Terminal board
USB
PC/FieldMate
+
–
SUPPLY
DO
PC/FieldMate
Distributor
PC/FieldMate
4 to 20 mA DC signal line
Relaying
terminals
Receiving
instrument
load resistance:
250 to 600 Ω
Figure 9.3 Connecting the HART Communicator
WARNING
Be sure to set parameters as “Protect” on the
writeprotectfunctionafternishofparameter
setting work.
Read Chapter 6 Menu P and Subsection 11.3.2,
how to use the write protect function in detail.
IMPORTANT
Ifthepowerofowmeteristurnedoffwithin30
seconds after parameters have been set, these
settings will be canceled. Accordingly, please
keep the power on for at least 30 seconds after
setting parameters.
9.2.2 Device Type Manager (DTM) and
Device Revision
WhenconguretheparametersusingFieldMate,
use the DTM (Device Type Manager) reading the
following table.
MODEL DTM
Name
Device
Type
Device
Revision
AXR
AXRHART7
DTM
AXR
(0x3757)
10
The device revision can be checked as follows.
[Root Menu]→Review→Review4→Flddevrev
