12.5 MODEL AND SUFFIX CODE
●WaferType
Model SufxCode Description Applicable Model
AXR025
AXR040
AXR050
AXR065
AXR080
AXR100
AXR150
AXR200
----------------------------------------
----------------------------------------
----------------------------------------
----------------------------------------
----------------------------------------
----------------------------------------
----------------------------------------
----------------------------------------
Size 25 mm (1 in.)
Size 40 mm (1.5 in.)
Size 50 mm (2 in.)
Size 65 mm (2.5 in.)
Size 80 mm (3 in.)
Size 100 mm (4 in.)
Size 150 mm (6 in.)
Size 200 mm (8 in.)
Two-wire Magnetic Flowmeter Integral Flowmeter
Two-wire Magnetic Flowmeter Integral Flowmeter
Two-wire Magnetic Flowmeter Integral Flowmeter
Two-wire Magnetic Flowmeter Integral Flowmeter
Two-wire Magnetic Flowmeter Integral Flowmeter
Two-wire Magnetic Flowmeter Integral Flowmeter
Two-wire Magnetic Flowmeter Integral Flowmeter
Two-wire Magnetic Flowmeter Integral Flowmeter
Use G
C
----------------------------------------
----------------------------------------
General-Purpose Use
Explosion proof Type (*1)
Output Signal
and
Communication
-D -----------------------------------
-E -----------------------------------
-J -----------------------------------
Integral Flowmeter with 4 to 20 mA DC Output and digital
communication (BRAIN protocol)
Integral Flowmeter with 4 to 20 mA DC Output and digital
communication (HART protocol) (*12)
Integral Flowmeter with 4 to 20 mA DC Output with digital
communication (HART5/HART7 protocol) (*13)
Power Supply 1 --------------------------------- Integral Flowmeter Operating voltage range 14.7 to 42 V DC
Two-wire system
Lining (*2) A ------------------------------ Fluorocarbon PFA
Electrode Material (*2) L ---------------------------
P ---------------------------
H ---------------------------
T ---------------------------
JIS SUS316L (AISI 316L SS/EN 1.4404 Equivalent)
Platinum-iridium
HASTELLOY C-276 Equivalent
Tantalum
Electrode Structure 1 ------------------------ Non-replaceable
Grounding Ring and
Grounding Electrode
Material (*2)
N --------------------
S --------------------
L --------------------
P --------------------
H --------------------
T --------------------
None (*3)
JIS SUS316 (AISI 316 SS/EN 1.4401 Equivalent)
JIS SUS316L or ASTM 316L (AISI 316L SS/EN 1.4404 Equivalent)
Platinum-iridium
HASTELLOY C-276 Equivalent
Tantalum
Process Connection
(*4) (*5)
-AA1 -------------
-AA2 -------------
-AD1 -------------
-AD2 -------------
-AD4 -------------
-AJ1 -------------
-AJ2 -------------
-AG1 -------------
ANSI Class 150 Wafer
ANSI Class 300 Wafer
DIN PN 10 Wafer (*6)
DIN PN 16 Wafer (*6)
DIN PN 40 Wafer (*6)
JIS 10K Wafer
JIS 20K Wafer
JIS F12 (JIS75M) Wafer
Size 200 mm (8.0 in)
Size 65 mm (2.5 in.) to
200 mm (8.0 in.)
Size 25 mm (1.0 in.) to
50 mm (2.0 in.)
Size 80 mm (3.0 in.) to
200 mm (8.0 in.)
Lay Length 1 ---------------
2 ---------------
Lay length code 1 (*7)
Lay length code 2 (*8)
Size 80 mm (3.0 in.) to
200 mm (8.0 in.)
Electrical Connection (*9) -0 -----------
-2 -----------
-4 -----------
JIS G1/2 female
ANSI 1/2 NPT female
ISO M20 × 1.5 female
Indicator (*10)(*11) 1 ---------
2 ---------
N --------
Integral Flowmeter with indicator (Horizontal)
Integral Flowmeter with indicator (Vertical)
Integral Flowmeter without indicator
Calibration B ----- Always B
Options /
 Optionalcode(ReadtheTableofOptionalSpecications)
Note: AnexclusiveUser’sManualmightbeattachedforproductswhosesufxcodeoroptionalcodescontaincode“Z”.
Please read it along with their standard manual.
*1: Forexplosionprooftypes,specifytypesofexplosionproofcerticationusingtheoptionalcodes.
FortheTIISameprooftype,selectoptionalcodeG11.AvailableonlyforJISG1/2femaleelectricalconnections.
 AvailableonlyforwiringofusingaameproofpackingadapterapprovedbyYokogawa.
 TheameproofmetalconduitwiringforTIISameprooftypeisnotpermitted.
*2: Usersmustconsiderthecharacteristicsofselectedwettedpartsmaterialandinuenceofprocessuids.
Theuseofinappropriatematerialscanresultintheleakageofcorrosiveprocessuidsandcauseinjurytopersonneland/ordamage
to plant facilities. It is also possible that the instrument itself can be damaged and that fragments from the instrument can contami-
natetheuser’sprocessuids.
Beverycarefulwithhighlycorrosiveprocessuidssuchashydrochloricacid,sulfuricacid,hydrogensulde,sodiumhypochlorite,
and high-temperature steam (150°C [302°F] or above). Contact Yokogawa for detailed information of the wetted parts material.
*3: Available only for metal piping.
*4: Mating dimensions are based on standards as follow:
ANSI: ASME B 16.5, DIN: DIN 2501, JIS: JIS B 2220 and JIS G 3443-2
