12-10

IM 01E30D01-01EN

<12. OUTLINE>

*5: Allowableuidpressureshouldalsobelimitedaccordingtouidtemperatureandpressure.

*6: Even when DIN PN10, 16, or 40 is required for a model of size 25 to 50 mm (1.0 to 2.0 in.), select PN40 (Process connection code:

AD4) because there is no difference in the dimensions of the mating faces.

Even when DIN PN10 or 16 is required for a model of size 65 to 150 mm (2.5 to 6.0 in.), select PN16 (Process connection code: AD2)

because there is no difference in the dimensions of the mating faces.

*7: Thedimensionsoflaylengthcode1arethesameasthoseofthePFAliningstandardlaylength(laylengthcode1)intheAXFseries.

Fordetails,read“EXTERNALDIMENSIONS”.

*8: Excluding the size of 65 mm, dimensions of lay length code 2 are the same as those of PFA lining replacement models (lay length code

2)inAXFseries.Laylengthsforspecialgaskets(optionalcodesGA,GC,GD)aredifferent.Fordetails,read“EXTERNALDIMEN-

SIONS”.

*9: For an explosion proof type except for TIIS, select “ANSI 1/2 NPT female” or “ISO M20 × 1.5 female”.

 FortheTIISameprooftype,select“JISG1/2female”andoptionalcodeG11.

*10: Selectfromamongtheguresattheright.

1 2 N

F1207.ai

*11: InthecaseoftheTIISameprooftype,select“withindicator”(code1or2).

*12: Output signal code “-E”: HART 5.(Output signal code “-J” is recommended for HART communication.)

*13: Output signal code “-J”: HART 5 or HART7 selectable. Specify HART 5 or HART 7 when ordering.
