<5. BASIC OPERATING PROCEDURES (USING THE DISPLAY UNIT)>
5-5
IM 01E30D01-01EN
5.2.2 Setting Mode
When the Setting Mode has been activated using the procedure from Subsection 5.2.1, parameters can be
selected for setting.
NOTE
If no operations are carried out for a period of 10 minutes in Setting Mode, the system will automatically
return to the Display Mode.
Format for Parameter Data
Depending on the type of parameter, data is formatted in one of the following three ways.
Format Typical display Content
(i) Selection-type
B21:Base Flow Unit
m
3
▲
m
3
▼ kl(Kiloliter)
B23:Flow Span
100 l/min
0000100. l/min
Rng:0.00001
→ 32000
C10:Tag No
FI-1101
FI-1201
Thedesireddataitemisselectedfromapredenedlist.
(ii) Numeric-type
B21:Base Flow Unit
m
3
▲
m
3
▼ kl(Kiloliter)
B23:Flow Span
100 l/min
0000100. l/min
Rng:0.00001
→ 32000
C10:Tag No
FI-1101
FI-1201
Data is set using the values in each digit and using the decimal
point.
(iii)
Alphanumeric-type
B21:Base Flow Unit
m
3
▲
m
3
▼ kl(Kiloliter)
B23:Flow Span
100 l/min
0000100. l/min
Rng:0.00001
→ 32000
C10:Tag No
FI-1101
FI-1201
Data is composed using alphanumeric characters (in the case of tag
numbers, special units, and the like). With this format, setting can be
carried out using up to 16 of the characters shown below.
Regarding the alphanumeric-type format (iii), the following alphanumerics are displayed in the following sequence:
#%&*+-./0123456789:<>ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz[space]
5.3 Parameter Setting Procedure
Once the system is in Setting Mode, the parameters for setting can be selected. Parameters that are frequently
used have been grouped together in Easy Setup in Menu B. This section provides a description of the
parameter setting procedure using B: Easy Setup and C: Basic Setup.
For more details regarding parameter content, read Chapter 6.
5.3.1 Setting Example for Selection-Type Data: Flow rate units
Thisexampledescribesthesettingoftheowrateunitsfortheselection-typeparameterB21: Base Flow Unit
from m
3
to l (Liter).
Setting mode
▲ P:Protect
B:Easy Setup
▼ C:Basic Setup
SET
F0504-1.ai
Start:
Major Item
Parameter
Search Mode
Setting mode
Major item
parameter
Major Item Parameter Search Mode has been
accessed in this screen.
Touch the
SET
switch to access B: Easy Setup.
NOTE
The▲and▼symbolstotheleftofthe
parameters indicate that additional setting items
to those being currently displayed may also be
selected. Use the
INC
switch to cycle through
these items.
