YOKOGAWA ADMAG AXR User Manual

<9. OPERATION VIA HART CONFIGURATION TOOL (HART 7)>
9-9
IM 01E30D01-01EN
e) Burst Mode
When the Burst mode is set to “Wired HART
Enabled”, the transmitter starts to send the data.
• Proceduretocallupthedisplay
DD
DTM
[Root Menu]→Detailedsetup→
HARToutput→Burstcondition→
BurstMessage1,2or3→Burst
mode→WiredHARTEnabled
IMPORTANT
In case of using HART7 Burst communication,
use Burst Message 1 in following settings:
Contents Menu Value
c) Update
Period
Set Burst Period 0.5 s (Default)
d) Burst Msg
Trigger Mode
Burst Msg
Trigger Mode
Continuous
(Default)
e) Burst mode Burst mode
Wired HART
Enabled
(3)EventNotication
When a setting change and a change of the Self-
diagnostics occur, device detect it as an event and
can transmit an alarm signal continuously.
Up to four events that occurred can be stored.
When using this function, set to Burst mode as
“Wired HART Enabled”.
(3-1) SetEventNotication
• Proceduretocallupthedisplay
DD
DTM
[Root Menu]→Detailedsetup
→HARToutput→Burst
condition→EventNotication→
→EventMask Set the status to detect
→Event
Notication
Retry Time
Set the retry time when the event
occur.
→MaxUpdate
Time
Set the retry time when the event
does not occur.
→EventDebounce
Interval
The setting of the minimum event
duration
→Event
Notication
Control
Stop the event monitor: Off
Shift to the monitor state: Enable
eventnoticationontoken-
passing data link layer
a) Event Mask
Set the status to detect in the Event Mask
parameter.
Status group 1 Mask to 7 Mask
Device Status Mask
Ext dev status Mask
Device Diagnostic Status 0 Mask
b) EventNoticationRetryTime/MaxUpdate
Time/EventDebounceInterval
SettoEventNoticationRetryTime,MaxUpdate
Time and Event Debounce Interval.
For EventNoticationRetryTime, set the value
that is smaller than Max Update Time.
EventNotication
Retry Time
/MaxUpdateTime
Event Debounce Interval
--- Off
0.5 s 0.5 s
1 s 1 s
2 s 2 s
4 s 4 s
8 s 8 s
16 s 16 s
32 s 32 s
1 min 1 min
5 min 5 min
10 min 10 min
15 min 15 min
30 min 30 min
45 min 45 min
60 min 60 min
c) EventNoticationControl
Select“Enableeventnoticationontoken-passing
data link layer” in the EventNoticationControl
parameter to shift to the monitor state:
(3-2) AcknowledgeEventNotication(DTM
only)
The transmission of the event message stops when
event is approved.
• Proceduretocallupthedisplay
DTM [Root Menu]→Detailed
setup→HARToutput→Burst
condition→EventNotication
→EventKnowledge→
→Acknowledge
EventNotication
Acquisition of the event number
and approval.
a) Get Event Number
Conrmthelatesteventnumber.
Execute AcknowledgeEventNotication
method.
1) Set “Enter Event Number” to “0”.
2) OK.
3) Set “Select Transaction” to “Trans 0: Read
EventNotication”.
4) OK.
5)Conrm“EventNumber”.
