<14. EXPLOSION PROTECTED TYPE INSTRUMENT>
14-7
IM 01E30D01-01EN
WARNING
IftheAXRismountedinanareawherethe
use of EPL Db equipment is required, it shall
be installed in such a way that the risk from
electrostatic discharges and propagating brush
dischargescausedbyrapidowofdustis
avoided.
(2) Electrical Connection
The type of electrical connection is stamped near
the electrical connection port according to the
following codes.
ISO M20x1.5 female M
ANSI 1/2NPT female N
F1401.ai
Screw Size Marking
(3) Installation
WARNING
• Groundingresistanceof100Ωorlessis
necessary.
When optional code A is selected, grounding
resistanceof10Ωorlessshallberequired.
• AllwiringshallcomplywithIEC60079-14,
and local installation requirements and local
electrical code.
• Inhazardouslocations,thecableentry
devicesshallbeofacertiedIECEx
ameprooftype,suitablefortheconditionsof
use and correctly installed.
• Unusedaperturesshallbeclosedwith
suitableameproofcertiedblanking
elements.(Theplugattachediscertiedas
theameproofandIP66orIP67asapartof
this apparatus.)
• IncaseofANSI1/2NPTplug,ANSI
hexagonal wrench should be applied to
screw in.
• Inordertopreventthegroundingring
conductor from loosening, the conductor
must be secured to the terminal, tightening
the screw with appropriate torque. Care must
be taken not to twist the conductor.
The grounding terminals are located on the inside
and outside of the terminal area.
Connect the cable to grounding terminal in
accordance with wiring procedure 1) or 2).
F1405.ai
1) Internal grounding
terminal
2)
External grounding
terminal
Figure 14.4 Wiring Procedure for Grounding
Terminals
(4) Operation
WARNING
• Afterde-energizing,delay5minutesbefore
opening.
• Takecarenottogeneratemechanical
spark when access to the instrument and
peripheral devices in hazardous locations.
(5) Maintenance and Repair
WARNING
Only personnel authorized by Yokogawa Electric
Corporation can repair the equipment.
WARNING
• Electrostaticchargemaycauseanexplosion
hazard. Avoid any actions that cause the
generation of electrostatic charge, such as
rubbing with a dry cloth on coating face of
product.
• Modicationoftheameproofjointisnot
allowed.
