ii
IM 01E30D01-01EN
Edition Date Page Revised Item
4th Sep. 2015 1-1 1. Added the NOTE for this manual.
1-2 1.1 (1) Added the WARNING for installation.
2-1 2.1 Changed the name plate in Figure 2.1.1
3-1 3.1 (3) Changed the lengths of straight runs, when installed two
ormoremagneticowmetersonasinglepipe.
3-13 3.3.4 Changed the table number. Added the recommended
inner diameter of gasket in Table 3.3.12.
4-3 4.3 (2) Changed the number of washer in Figure 4.3.1.
4-4 4.4 Changed the IMPORTANT for grounding.
Changed the sentence in Figure 4.4.3.
4-14 to 4-17 4.6 Added the sentence for grounding in Table 4.6.5 to Table
4.6.7.
6-11 6.3 (8) Added the default value for H40.
6-20 6.4 (2) Changed the name plate.
6-22 6.4 (3) Changed the sentence for D20.
6-31 6.4 (7) Added the sentence for H40.
7-3 7.2.1 Added the load resistance in Figure 7.2.
Added the IMPORTANT for communication.
8-1 8.1 Changed the name plate.
8-2 8.3 Added the load resistance in Figure 8.3.
9-1 9.1 Changed the name plate.
9-2 9.3 Added the load resistance in Figure 9.3.
9-9 9.8.3 (2) Added the IMPORTANT for HART7 Burst communication.
11-2 11.2 Added the IMPORTANT for component replacement.
12-5 12.1 Changed the sentence for gasket size.
12-7 12.3 Deleted the marks.
Added the performance specification in EMC Conformity
Standards.
Changed the table and note for PED.
12-13 12.6 Changed the allowable current, when selected the
optional code A.
12-15 DeletedthenoteforIECExcertication.
12-23 12.7 Changed the table for flameproof packing adapter and
added the parts number.
13-1 13 (1) Changed the table and note for PED.
14-1 14. Added the NOTE for this manual.
14-7 14.4 Changed the table for flameproof packing adapter and
added the parts number.
A1-2 A1.2.5 Added the Proof Test Coverage in Table A1.2.2.
