6-5
IM AQ6370D-01EN
Waveform Display
6
Changing Settings Using the Mouse
The mouse can be used in the overview window to change the display scale settings.
Changing the Center Wavelength (Center Frequency)
1.
Move the mouse pointer into the overview window.
2.
Drag in the zoom area surrounded by a dotted line.
When doing so, the mouse pointer changes to a hand tool.
Changing the Zoom Start/Stop Wavelength
1.
Move the mouse pointer into the overview window.
2.
Drag a vertical dotted line of the zoom area.
When doing so, the mouse pointer changes to an arrow.
Specifying a New Zoom Area
1.
Move the mouse pointer into the overview window.
2.
Drag outside of the zoom area. A new zoom area is created.
When doing so, the mouse pointer changes to a plus (+) sign.
Note
For information on power measurement inside the zoom area, see section 7.4, “Power
Measurement.”
6.1 Zooming In/Out on Waveforms
