7-64
IM AQ6370D-01EN
When the Logging Item Is MULTI-PEAK
• Setting the Minimum Peak/Bottom Difference of the Mode Judgment Reference
3.
Press the ANALYSIS PARAMETER soft key. The menu for detecting peak values
is displayed.
4.
Press the MODE DIFF soft key. The screen for setting the mode judgment
reference is displayed.
5.
Enter the mode judgment reference using the rotary knob, arrow keys, or numeric
keypad.
6.
Press nm/ENTER.
Note
For a description of the mode judgment reference, see “MODE DIFF” in section 6.12.
When the Logging Item Is DFB-LD
3.
Press the ANALYSIS PARAMETER soft key. The DFB-LD analysis parameter
setting screen appears.
For the operating procedure, see steps 4 to 6 in section 7.5.
For parameter descriptions, see appendix 3.
If you change a parameter, the value specified in section 7.5 will also change
(because the parameter is shared).
7.15 Analysis Data Logging
To Next Page
