8-5
IM AQ6370D-01EN
Saving/Loading Data
8
Explanation
Up to 64 data can be saved.
It is often useful to temporarily save waveform data for redisplay at a later time. The
following data can be saved.
Types of Data Display in List (ATTR Field)
Measured waveforms MEAS
Normalized displayed waveforms NORM A, NORM B, NORM C
Maximum value detection display waveforms MAX_H
Minimum value detection display waveforms MIN_H
Curve-fit waveforms CRV FIT A, CRV FIT B, CRV FIT C
Peak curve fit waveforms PKCVFIT A, PKCVFIT B, PKCVFIT C
LOG calculation display waveforms A-B, B-A, A+B, C-D, D-C, C+D, D-E, E-D, D+E,
C-F, F-C, C+F, E+F, F-E, E+F, F-E, E+F
Linear calculation display waveforms A+B LIN, A-B LIN, B-A LIN, 1-k(A/B), 1-k(B/A),
C+D LIN, C-D LIN, D-C LIN, D+E LIN, D-E LIN,
E-D LIN, C+F LIN, C-F LIN, F-C LIN, E+F LIN,
E-F LIN, F-ELIN
8.2 Temporarily Saving and Redisplaying Traces to and from Internal Memory
To Next Page
