YOKOGAWA AQ6370D User Manual

8-19
IM AQ6370D-01EN
Saving/Loading Data
1
2
3
4
5
6
7
8
9
10
11
App
Index
"SMPLINTVL", 0.02
Measurement sampling interval
"HIGH 1"
Measurement sensitivity
"MEAS"
Measurement identifier
"LSUNT",0
Vertical axis scale mode (0: dBm, 1: dBm/nm)
"NMSKV","OFF"
Noise mask setting
(NMSKV:VERTICAL, NMSKH:HOLIZONTAL)
"RESCORE",0
Resolution correction setting (0: OFF, 1: ON)
"SMOOTH",0
Smoothing setting (0: OFF, 1: ON)
"FIBERTYPE",0
Fiber connector setting (0: NORM, 1: ANGLED)
"MEASWL",1
Wavelength in the air or in a vacuum (0: AIR, 1: VACUUM)
"SWPSPD",0
Sweep speed (0: 1x, 1: 2x)
"NEBWCAL0",10000
Resolution calibration coefficient
"NEBWCAL1",0
Resolution calibration coefficient
"NEBWCALWL",1550
Resolution calibration wavelength
"RESPARM",10372
Wavelength resolution RMS coefficient
"FREQPARM",10372
Frequency resolution RMS coefficient
The reference level and main level scale are saved to one of the following depending on
the vertical scale.
Main level scale
Vertical Axis Scale Save Format Description
LOG “REFL”,***.* Reference level
“LSCL”,***.* Level scale
Linear “REFL”,***.* Reference level
“LSCL”,***.* Level scale
“BASEL”,****.** Base level
Sub-level scale
Vertical Axis Scale Save Format Description
LOG “REFL”,***.* Reference level
“SSCLLOG”,***.* Level scale
“LOFST”,***.* Level offset
Linear “REFL”,***.* Reference level
“SSCLN”,***.* Level scale
“SMIN”,****.** Base level
DB/km “REFL”,***.* Reference level
“SSKM”,**.* Level scale
“OFSKM”,***.* Offset level
“LENG”,**.*** Optical fiber length
% “REFL”,***.* Reference level
“SSPS”,***.* Level scale
“SMINP”,***.* Base scale
8.3 Saving/Loading Displayed Data
