8-20
IM AQ6370D-01EN
Measurement Sensitivity
The data below is saved as measurement sensitivity depending on the measurement
sensitivity type.
Format Measurement Sensitivity Type
"NORM-HOLD" NORM/HOLD
"NORM-AUTO" NORM/AUTO
"NORMAL" NORMAL
"MID" MID
"HIGH 1" HIGH 1 (CHOP OFF)
"HIGH 2" HIGH 2 (CHOP OFF)
"HIGH 3" HIGH 3 (CHOP OFF)
"MID_SW" MID (SWITCH ON)
"HI1_SW" HIGH1 (SWITCH ON)
"HI2D_SW" HIGH2 (SWITCH ON)
"HI3D_SW" HIGH3 (SWITCH ON)
Note
If PEAK HOLD is selected in pulse light measurement mode, a P- is added to the front of the
data above. Similarly, if EXTERNAL TRIGGER is selected, an E- is added.
Measurement Identifier
The data below is saved as a waveform identifier depending on the waveform type.
Format Waveform Format Waveform Format Waveform
Type Type Type
"MEAS" WRITE "E-D" E-D(LOG) "C+FL" C+F(LIN)
"MAXH" MAX HOLD "C+D" C+D(LOG) "C-FL" C-F(LIN)
"MINH" MIN HOLD "D+E" D+E(LOG) "F-CL" F-C(LIN)
"RAVG" ROLL AVG "C+DL" C+D(LIN) "E+FL" E+F(LIN)
"A-B" A-B(LOG) "C-DL" C-D(LIN) "E-FL" E-F(LIN)
"B-A" B-A(LOG) "D-CL" D-C(LIN) "F-EL" F-E(LIN)
"A+B" A+B(LOG) "D+EL" D+E(LIN) "NORM A" NORMALIZE A
"A-BL" A-B(LIN) "D-EL" D-E(LIN) "NORM B" NORMALIZE
"B-AL" B-A(LIN) "E-DL" E-D(LIN) "NORM C" NORMALIZE
"A+BL" A+B(LIN) "C-F" C-F(LOG) "CVFT A",** CRV FIT A
"1-K(A/B)",*****.**** 1-k(A/B) "F-C" F-C(LOG) "CVFT B",** CRV FIT B
"1-K(B/A)",*****.**** 1-k(B/A) "E-F" E-F(LOG) "CVFT C",** CRV FIT C
"C-D" C-D(LOG) "F-E" F-E(LOG) "CVFTPK A",** PK CRV FIT A
"D-C" D-C(LOG) "C+F" C+F(LOG) "CVFTPK B",** PK CRV FIT B
"D-E" D-E(LOG) "E+F" E+F(LOG) "CVFTPK C",** PK CRV FIT C
8.3 Saving/Loading Displayed Data
To Next Page
