Saving/Loading Data
1
2
3
4
5
6
7
8
9
10
11
App
Index
Selecting the Storage Medium
6.
Press the MEMORY soft key to select INT (internal memory) or EXT (USB storage
media).
The file list of the selected medium appears.
Entering the Name of a File to Save
If you do not set a file name, the file will automatically be assigned a name using a serial
number or date.
For instructions on how to create directories and sort the file list, see page 8-9.
7.
Using the rotary knob or arrow keys, move the cursor to the line in the file list
displaying NEW FILE.
8.
Press the FILE NAME soft key. The text entry window and corresponding soft key
menu appear.
9.
Follow the instructions in section 4.3 to enter a file name.
10.
Press the DONE soft key. The file name is confirmed, and the screen returns to
the previous level.
NEW FILE
8.10 Saving and Loading Logging Data
