Zebra DS2278 Reference Guide

Standard Default Parameters A - 3
Beeper Tone 145 91h Medium 4-8
Beeper Duration 628 F1h 74h Medium 4-9
Suppress Power Up Beeps 721 F1h D1h Do Not Suppress 4-9
Direct Decode Indicator 859 F2h 5Bh Disable 4-10
Low Power Mode 128 80h Enable 4-11
Time Delay to Low Power Mode 146 92h 100 msec 4-12
Timeout to Low Power Mode from
Auto Aim
729 F1h D9h 15 sec 4-14
Battery Preservation Mode 1765 F8h 06h E5h Enable 4-15
Trigger Mode (or Hand-Held Trigger
Mode)
138 8Ah Standard (Level) 4-16
Hands-Free Mode 630 F1h 76h Enable 4-17
Hand-Held Decode Aiming Pattern 306 F0h 32h Enable 4-18
Hands-Free (Presentation) Decode
Aiming Pattern
590 F1h 4Eh Enable Hands-Free
(Presentation) Decode Aiming
Pattern on PDF
4-19
Picklist Mode 402 F0h 92h Disable Picklist Mode Always 4-20
Continuous Bar Code Read 649 F1h 89h Disable 4-21
Unique Bar Code Reporting 723 F1h D3h Enable 4-21
Decode Session Timeout 136 88h 9.9 Seconds 4-22
Hands-Free Decode Session Timeout 400 F0 90 15 4-22
Timeout Between Decodes, Same
Symbol
137 89h 0.5 Seconds 4-23
Timeout Between Decodes, Different
Symbols
144 90h 0.1 Seconds 4-23
Decode Mirror Images (Data Matrix
Only)
537 F1h 19h Auto 4-24
Mobile Phone/Display Mode N/A N/A N/A 4-24
PDF Prioritization 719 F1h CFh Disable 4-25
PDF Prioritization Timeout 720 F1h D0h 200 ms 4-25
Decoding Illumination 298 F0h 2Ah Enable 4-26
Illumination Brightness 669 F1h 9Dh High 4-26
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number

Zebra DS2278 Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
LED indicators	Yes
Built-in display	No
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, Interleaved 2 of 5, Plessey, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Battery life	84 h
Input voltage	4.5 - 5.5 V
Battery capacity	2400 mAh
Power source type	Battery, DC
Number of batteries supported	1
USB version	2.0
Bluetooth version	4.0
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	90 mm
Width	66 mm
Height	175 mm
Weight	214 g
