A - 4 DS2278 Digital Scanner Product Reference Guide
Low Light Scene Detection 810 F2h 2Ah Dim Illumination Low Light
Assist Scene Detection
4-27
Motion Tolerance (Hand-Held Trigger
Mode Only)
858 F2h 5Ah Less
4-28
Product ID (PID) Type 1281 F8h 05h 01h Host Type Unique
4-29
Product ID (PID) Value 1725 F8h 06h BDh 0
4-29
ECLevel 1710 F8h 06h AEh 0
4-30
Miscellaneous Options
Enter Key N/A N/A N/A
4-31
Tab Key N/A N/A N/A
4-31
Transmit Code ID Character 45 2Dh None
4-32
Prefix Value 99, 105 63h, 69h 7013 <CR><LF>
4-33
Suffix 1 Value
Suffix 2 Value
98, 104
100, 106
62h, 68h
64h, 6Ah
7013 <CR><LF>
4-33
Scan Data Transmission Format 235 EBh Data As Is
4-34
FN1 Substitution Values 103, 109 67h, 6Dh 7013 <CR><LF>
4-36
Transmit “No Read” Message 94 5E Disable
4-37
Unsolicited Heartbeat Interval 1118 F8h 04h 5Eh Disable
4-38
Send Versions
Software Version N/A N/A N/A
4-39
Serial Number N/A N/A N/A
4-39
Manufacturing Information N/A N/A N/A
4-39
Signature Capture Preferences
Signature Capture 93 5Dh Disable
6-3
Signature Capture File Format
Selector
313 F0h 39h JPEG
6-4
Signature Capture Bits per Pixel
(BPP)
314 F0h 3Ah 8 BPP
6-5
Signature Capture Width 366 F4h F0h 6Eh 400
6-6
Signature Capture Height 367 F4h F0h 6Fh 100
6-6
Signature Capture JPEG Quality 421 F0h A5h 65
6-6
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
