Data Capture 2 - 3
None Single green flash Initial connection.
None Red (solid) Charge error.
Parameter Programming
Long low/long high beeps Red Input error, incorrect bar code or
Cancel
scanned,
wrong entry, incorrect bar code programming
sequence; remain in program mode.
High/low beeps Green Keyboard parameter selected. Enter value using bar
code keypad.
High/low/high/low beeps Green Successful program exit with change in the parameter
setting.
ADF Programming
Low/high/low beeps None ADF transmit error.
High/low beeps Green Number expected. Enter another digit. Add leading
zeros to the front if necessary.
Low/low beeps Green Alpha expected. Enter another alphabetic character or
scan the
End of Message
bar code.
High/high beeps Green blinking ADF criteria or action is expected. Enter another criteria
or action or scan the
Save Rule
bar code.
High/low/low beeps Green All criteria or actions cleared for current rule, continue
entering rule.
High/low/high/low beeps Green
(turns off blinking)
Rule saved. Rule entry mode exited.
Long low/long high beeps Red Rule error. Entry error, wrong bar code scanned, or
criteria/action list is too long for a rule. Re-enter criteria
or action.
Low beep Green Deleted last saved rule. The current rule is left intact.
Low/high/high beeps Green All rules deleted.
Long low/long high/long
low/long high beeps
Red Out of rule memory. Erase some existing rules, then try
to save rule again.
Long low/long high/long low
beeps
Green
(turns off blinking)
Cancel rule entry. Rule entry mode exited because of
an error or the user asked to exit rule entry.
Macro PDF
Two low beeps None File ID error. A bar code not in the current MPDF
sequence was scanned.
Two long low beeps None File ID error. A bar code not in the current MPDF
sequence was scanned.
Table 2-1 Digital Scanner Beeper and LED Indications (Continued)
Beeper Sequence LED Indication
