2 - 4 DS2278 Digital Scanner Product Reference Guide
Three long low beeps None Out of memory. There is not enough buffer space to
store the current MPDF symbol.
Four long low beeps None Bad symbology. Scanned a 1D or 2D bar code in a
MPDF sequence, a duplicate MPDF label, a label in
an incorrect order, or trying to transmit an empty or
illegal MPDF field.
Five long low beeps None Flushing MPDF buffer.
Fast warble beep None Aborting MPDF sequence.
Low/high beeps None Flushing an already empty MPDF buffer.
Host Specific
USB only
Four high beeps None
Digital
scanner has not completed initialization. Wait
several seconds and scan again.
RS-232 only
High/high/high/low beeps Red RS-232 receive error.
High beep None A <BEL> character is received when Beep on <BEL> is
enabled.
Host Controlled Digital Scanner LEDs
None Green (slow blink) Digital scanner connected to 123Scan.
None Red (fast blink) File being transferred to the digital scanner (parameters
and firmware).
None Red (slow blink) Firmware being activated on the digital scanner, loaded
into memory.
None Green (solid) Programming completed successfully (parameters and
firmware).
None Red (blink) Loading the SMS package to the digital scanner.
None Red (solid) Error state.
Table 2-1 Digital Scanner Beeper and LED Indications (Continued)
