Zebra FX7500 Integration Guide

About This Guide
11
Notational Conventions
The following conventions are used in this document:
• “RFID reader”, “reader”, or “FX Series” refers to the Zebra FX7500 and/or FX9600 RFID readers.
• Bullets (•) indicate:
• Action items
• Lists of alternatives
• Lists of required steps that are not necessarily sequential.
• Sequential lists (e.g., those that describe step-by-step procedures) appear as numbered lists.
Related Documents and Software
The following documents provide more information about the reader.
• FX7500 RFID Reader Quick Start Guide, p/n MN000070Axx.
• FX9600 RFID Reader Quick Start Guide, p/n MN-003087-xx.
• FX Series Reader Software Interface Control Guide, p/n 72E-131718-xx. Describes Low Level
Reader Protocol (LLRP) and Reader Management (RM) extensions for the reader.
• RFID Demo Applications User Guide, p/n 72E-160038-xx. Provides instructions for using sample
applications which demonstrate how to use Zebra RFID readers.
• FX Series Embedded SDK Installation Guide. Provides instructions for installing the embedded
SDK for C and Java.
• FX Series Embedded SDK Sample Application Guide. Explains how to use the embedded sample
application with an integrated development environment.
• FX Series Embedded SDK Programmers Guide. Provides instructions for creating new embedded
applications.
• RFID3 API
• EPCglobal Low Level Reader Protocol (LLRP) Standard
For the latest version of these guides and software, visit: www.zebra.com/support.

Zebra FX7500 Specifications

General

Interface	USB
Product color	White
LED indicators	Activity, Power, Status
Housing material	Aluminium, Metal, Plastic
Battery type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84719000

Weight and Dimensions

Depth	43.2 mm
Width	149.9 mm
Height	195.6 mm
Weight	860 g
