Zebra FX7500 Integration Guide

13
Quick Start
Introduction
This chapter provides a Quick Start setup demonstration.
Quick Start Demonstration
The Quick Start demonstration offers a simple, temporary way to quickly set up the reader and read tags.
The demonstration includes:
• Step 1, Setup on page 13
• Step 2, Connecting to the Reader on page 14
• Step 3, First Time / Start-Up Login on page 15
• Step 4, Set Region on page 16
• Step 5, Read Tags on page 18
Step 1, Setup
For information on complete component kits available from Zebra, see Appendix , Technical
Specifications.
1. Unpack the reader. See Unpacking the Reader on page 27.
2. Place the reader on a desktop.
3. Connect the antenna to antenna Port 1. See Figure 1 and Figure 2.
4. Connect the Ethernet cable to the Ethernet port. See Figure 1.and Figure 2.
5. To connect to power:
• When using an AC power supply, connect the AC power supply to a power outlet and connect to
the power port.
• When using PoE or PoE+, plug the ethernet cable into the PoE/PoE+ injector.
6. Wait for the green power LED to stay lit. See System Start-up/Boot LED Sequence on page 38 for
boot-up details.
NOTE:Connecting the reader to a subnet that supports DHCP is recommended. This Quick Start
procedure is not guaranteed to work if DHCP is disabled in the reader and if the reader is connected
directly to a PC.

Zebra FX7500 Specifications

General

Interface	USB
Product color	White
LED indicators	Activity, Power, Status
Housing material	Aluminium, Metal, Plastic
Battery type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84719000

Weight and Dimensions

Depth	43.2 mm
Width	149.9 mm
Height	195.6 mm
Weight	860 g
