Zebra FX7500 Integration Guide

133
Static IP Configuration
Introduction
This chapter describes three methods of setting the static IP address on an FX7500 and FX9600 RFID
Readers.
Reader IP Address or Host Name is Known
Set the Static IP Using the Web Console
1. Browse the device using the host name, for example: FX7500CD3B1E.
2. Log onto the device.
Figure 100 Reader Administration Console Login Window
3. Click Communication.
4. Set Obtain IP Address via DHCP to Off and enter all required information.

Zebra FX7500 Specifications

General

Interface	USB
Product color	White
LED indicators	Activity, Power, Status
Housing material	Aluminium, Metal, Plastic
Battery type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84719000

Weight and Dimensions

Depth	43.2 mm
Width	149.9 mm
Height	195.6 mm
Weight	860 g
