Zebra FX7500 Integration Guide

Administrator Console
85
• The package must contain a stop script in the name of stop_packageName.sh to stop the binary or
binaries in the package. For example, if the package name is package-1_2.1_all.deb (package 1 version
2.1), the name of stop script must be stop_package-1.sh.
Reader Profiles
Select Profiles in the selection menu to view the Reader Profiles window, which shows the current profiles
on the reader and allows performing profile-related operations.
The window displays a set of provided configuration files, or profiles, that a user can re-use and/or modify
depending on the reader application or use case. The profiles serve as configuration examples.
Figure 54 Reader Profiles Window
The
Reader Profiles window functions are:
• Available Profiles in the Reader - Displays the available reader profiles.
• Import - Click to open a file dialog and pick a profile (XML file) from the local PC and import it into
the reader.
• Export - Select an available profile and click Export to export profile information and save an XML
file onto the local drive.
• Set Active - Activates a selected profile. Select an available profile and click Set Active to load the
profile content in the reader.
NOTE: The reader executes the packages with the privileges of rfidadm user account. See the user
accounts section for information on rfidadm user privileges.
NOTE: Because the Reader Profiles window uses an applet to connect to the reader, enable JVM
support on the browser in order for this window to function properly.
CAUTION:Swapping profiles between readers using static IP addresses is not recommended. Activating
a profile with a static IP address changes the IP of the reader, and if not done properly can
make the reader inaccessible.

Zebra FX7500 Specifications

General

Interface	USB
Product color	White
LED indicators	Activity, Power, Status
Housing material	Aluminium, Metal, Plastic
Battery type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84719000

Weight and Dimensions

Depth	43.2 mm
Width	149.9 mm
Height	195.6 mm
Weight	860 g
