Zebra FX7500 Integration Guide

Administrator Console
54
Other Custom Command Operation Statistics
Select Other Custom to view the Other Custom Command Operation Statistics window. This window provides
options to view the statistics of read points for the custom operations the reader supports.
Figure 33 NXP Custom Command Operation Statistics Window
• Choose ReadPoint - Select a specific read point from the drop-down list to display the statistics, or
select
All to view the combined statistics for all read points.
• QTOperation - Displays the number of successful (and failed) QT operations performed on Monza4
QT tags.
• Reset Statistics - Resets all the success and failure counts for all the read points.
• Refresh Interval - Sets the refresh interval (in seconds) for this window. The statistics information for
the chosen read point is refreshed every
N seconds (where N is the set refresh interval). The
minimum value is 10 seconds and the maximum value allowed is 86,400 seconds. Input a new
value and click
Change to set a new interval.

Zebra FX7500 Specifications

General

Interface	USB
Product color	White
LED indicators	Activity, Power, Status
Housing material	Aluminium, Metal, Plastic
Battery type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84719000

Weight and Dimensions

Depth	43.2 mm
Width	149.9 mm
Height	195.6 mm
Weight	860 g
